| Engine Series: |
KT50-G |
| Engine Type: |
16 Cylinders, V type |
| Displacement: |
50.3 L |
| Rated Speed: |
1500rpm-1800rpm |
| Rated Power: |
1097kW(1470HP)-1384kW(1855HP) |
| Aspiration Method: |
T-charged |
| Emission Standard: |
Euro II |
| Fuel Consumption: |
≤210g/kW.h |
| Packing Size(L*W*H): |
2541*1560*1953 |
| Gross Weight: |
5410 Kg |
| Delivery Time: |
7-15 working days |
| Payment Terms: |
T/T ,L/C |
|
|
|
CCEC KT50-G Diesel Engine for Agricultural Pump Application
| General Information of CCEC KT50-G Diesel Engine for Agricultural Pump Application |
| Engine Series |
KT50-G |
| Engine Type |
12 Cylinders,V type |
| Displacement |
50.3L |
| Bore*Stroke(mm) |
159*159 |
| Compression Ratio |
14.5:1 |
| Net Weight(with flywheel&alternator) |
5360kg |
| Overall Dimension(L*W*H) |
2978mm*2080mm*1780mm |
| Technical Specification of CCEC KT50-G Diesel Engine for Agricultural Pump Application |
| Certification |
Euro II |
| Aspiration |
T-charged |
| Fuel System |
Direct Injection |
| Starting Method |
Electric/Mechanical |
| Eletrical System(Starter Motor/Alternator) |
12V/24V |
| Governor Type |
Electronic |
| Cooling Method |
Water Cooled |
| Performance Data of CCEC KT50-G Diesel Engine for Agricultural Pump Application |
| Rated Power |
1097kW(1470HP)-1384kW(1855HP) |
| Rated Speed |
1500rpm-1800rpm |
| Fuel Consumption |
≤210g/kW.h |
| Idel Speed |
725-775rpm |
| Governing Rate |
≤5% |
| Model of CCEC KT50-G Diesel Engine for Agricultural Pump Application |
| Models Available from CCEC China Joint Venture |
Rated Power@Rated Speed |
| KTA50-G3 |
1097KW@1500rpm |
| KTA50-G8 |
1200KW@1500rpm |
| KTA50-G9 |
1384KW@1800rpm |
Click model name to check detailed specifications of each engine:KTA50-G3,KTA50-G8,KTA50-G9.
We can also supply genuine brand new spare parts for this model. For more info click here: CCEC KT50-G spare parts.
/**/
