| Engine Series: |
6LT8.9-C |
| Engine Type: |
6 Cylinders in Line |
| Displacement: |
8.9 L |
| Rated Speed: |
2100rpm-2200rpm |
| Rated Power: |
164kW(220HP)-264kW(360HP) |
| Aspiration Method: |
Turbocharged |
| Emission Standard: |
Euro I、Euro II |
| Fuel Consumption: |
210g/kW.h-235g/kW.h |
| Packing Size(L*W*H): |
1560*950*1450 |
| Gross Weight: |
700 Kg |
| Delivery Time: |
7-15 working days |
| Payment Terms: |
T/T ,L/C |
|
|
|
DCEC 6LT8.9-C Diesel Engine for Mining Pump Application
| General Information of DCEC 6LT8.9-C Diesel Engine for Mining Pump Application |
| Engine Series |
6LT8.9-C |
| Engine Type |
6 Cylinders,In Line |
| Displacement |
8.9L |
| Bore*Stroke(mm) |
114*145 |
| Compression Ratio |
16.6:1 |
| Net Weight(with flywheel&alternator) |
650kg |
| Overall Dimension(L*W*H) |
1400mm*800mm*1040mm |
| Technical Specification of DCEC 6LT8.9-C Diesel Engine for Mining Pump Application |
| Certification |
Euro I、Euro II |
| Aspiration |
Turbocharged |
| Fuel System |
Direct Injection |
| Starting Method |
Electric/Mechanical |
| Eletrical System(Starter Motor/Alternator) |
12V/24V |
| Governor Type |
Electronic/Mechanical |
| Cooling Method |
Water Cooled |
| Performance Data of DCEC 6LT8.9-C Diesel Engine for Mining Pump Application |
| Rated Power |
164kW(220HP)-264kW(360HP) |
| Rated Speed |
2100rpm-2200rpm |
| Fuel Consumption |
210g/kW.h-235g/kW.h |
| Idel Speed |
800rpm |
| Max. Continuous Running Altitude |
2000 m |
| Model of DCEC 6LT8.9-C Diesel Engine for Mining Pump Application |
| Models Available from DCEC China Joint Venture |
Rated Power@Rated Speed |
| 6LTAA8.9-C220 |
220HP@2200rpm |
| 6LTAA8.9-C240 |
240HP@2200rpm |
| 6LTAA8.9-C260 |
260HP@2200rpm |
| 6LTAA8.9-C295 |
295HP@2100rpm |
| 6LTAA8.9-C300 |
300HP@2200rpm |
| 6LTAA8.9-C325 |
325HP@2200rpm |
| 6LTAA8.9-C340 |
340HP@2200rpm |
| 6LTAA8.9-C360 |
360HP@2200rpm |
Click model name to check detailed specifications of each engine:6LTAA8.9-C220,6LTAA8.9-C240,6LTAA8.9-C260,6LTAA8.9-C295,6LTAA8.9-C300,6LTAA8.9-C325,6LTAA8.9-C340,6LTAA8.9-C360.
We can also supply genuine brand new spare parts for this model. For more info click here: DCEC 6LT8.9-C spare parts.
/**/
